Multi-use Cutters
Bolt on to cutter holders and can be rotated 2-4 times prior to replacement.
.avif)
Cutter Holders
Can be individually replaced allowing user to change number of active cutters or remove & replace as needed.
.avif)
Reusable Anvils
Adjustable to maintain optimal cutting tolerances. Anvils can be flipped and reused prior to replacement.
Patented SSP
Severe Shock Protection [SSP] protects drive system in the event that the shaft stop.
Removable Screen
A wide rand of screens are available with various holes sizes and configurations to optimize particle size.
.avif)
Easy Maintenance
Designed with "tool-less" access to cutting chamber make service and maintenance safe and easy.
.avif)
Direct Drive
Simple and efficient drive with not belts to maintain.
Details
The Uni-Shear® SR900 is designed to accept a wide range of pre-shredded materials. This heavy duty single rotor machine can process tires, non-ferrous metals, copper wire, RDF, plastics and much more. Internal screens with hole sizes ranging from 12 to 50mm (½ to 2 in) are available and drive options of 224 or 298 kW (300 or 400 hp) provide sufficient power and torque to process most anything. Low parts cost and easy service access are among the many features of the SR900 grinder.
Videos
Specifications
| Shredder Model | Uni-Shear® SR900(80) |
|---|---|
| Drive | In-line direct-drive |
| Number of Motors | |
| Power (Range) | 224 - 298 kW (300 - 400 hp) |
| Voltage | 460/3/60 standard; other options available |
| Voltage Options | |
| Autochop Feature | |
| Shock Load Protection | |
| Cutter Thickness (nominal) | |
| Cutter Diameter | 80 |
| Cutter Material | |
| Shaft Diameter | |
| Number of Cutters | |
| Rotor Diameter | 875 mm (34½ in) |
| Rotor Speed (rpm) | |
| Screen Sizes | 12 to 150 mm (½ - 6 in) |
| Active Rotor Length | |
| Cutting Chamber (WxL) | 1,045 x 2,040 mm (41 x 80 in) |
| Hopper Capacity | |
| Machine Length | 5,608 mm (220 in) |
| Machine Width | 3,270 mm (128 in) |
| Machine Height | 4,853 mm (191 in) |
| Machine Weight | 21,500 kg (47,800 lbs) |
| Hydraulic Ram | |
| Hopper Opening | |
| Hopper Height | |
| Stand Height | |
| HPU Configuration | |
| HPU Dimensions | |
| HPU Weight |
